| Part Number | DC BreakdownVo ltage(VBR)@100V/s (V) | Tolerance of VBR(V) | Impulse Spark-over Voltage@1KV/μs (V) | Arc Voltage (Va)@1A(V) | Impulse Discharge Current@8/20μs (kA) | Insulation Resistance (GΩ) | @ DC (V) | Capacitance CO 0.5VDC@1MHZ(pF) | Size L*W*H(mm) | 搜索 | |
| BGO1001A05-LC2 | 1000 | ≥800 | ≤2000 | ?60 | 5 | ≥1 | 100 | ≤1.5 | φ8x7.0 | ||
| B5G470L | 470 | 376-564 | ≤850 | ～15 | 5 | ≥1 | 100 | ≤1 | φ5.5x6 | ||
| B5G600L | 600 | 480-720 | ≤950 | ～15 | 5 | ≥1 | 100 | ≤1 | φ5.5x6 | ||
| B5G800L | 800 | 640-960 | ≤1600 | ～15 | 5 | ≥1 | 100 | ≤1 | φ5.5x6 | ||
| B5G3600 | 3600 | 2880-4680 | ≤4700 | ～15 | 3 | ≥1 | 100 | ≤1 | φ5.5x6 | ||
| B8G600M | 600 | 480-720 | ≤1400 | ～15 | 10 | ≥1 | 100 | ≤1.5 | φ8x6 | ||
| BXD3000SA03M-05 | 3000 | 3200~5200 | ≥2000 | ~100 | 3 | ≥1 | 100 | ~6 | 8.5x5.2x6.8 | ||
| B8G3600L | 3600 | 2880-4320 | ≤6000V(@1.2/50μs 6kV) | ～15 | 5 | ≥1 | 100 | ≤1.5 | φ8x6 | ||
| BXD3000SA03M-D | 3000 | 3200~4800 | ≤3000 | ~100 | 3 | ≥1 | 100 | ~500 | 8.8x6.2x8.7 | ||
| BGO6000A03-LB2 | 600 | ≥480 | ≤1500 | / | 3 | / | / | ≤1.5 | Φ5.5x6.0 | ||
| BGO6000A10-LC2 | 600 | ≥480 | ≤1500 | ?40 | 10 | ≥1 | 100 | ≤1.5 | φ8x7.0 | ||
| BGO1001A10-LC2 | 1000 | ≥800 | ≤2500 | ?60 | 10 | ≥1 | 100 | ≤1.5 | φ8x7.0 |
